TOOLING FOR GE LM2500 LM5000 LM6000

Part No: GE LM2500 LM5000 LM6000 tooling
ANTONI No: GE LM2500 LM5000 tooling (AN/UT)
Model: GE LM2500 LM5000 LM6000

Available Tooling for GE series LM2500 LM5000 LM6000

contact us for more details on your requirements

Item # Description LM6000 Part #
1 PUSHER,NO.3 BEARING INNER RACE 1C5696 / 2C6002
2 Tool Set, Jackscrew 1C6804
3 TOOL SET-RADIAL
DR SHAFT		 1C6361
4 Fixture Set, Mating Seal Removal 1C8182
5 SPREAD,BUSH-AGB
LINK MNT		 1C8196
6 FIX,AFT-LIFT/TURN,LPC 1C9053
7 Fixture, Lift – LPC Rotor and Stator,
Horiz		 1C9054
8 PULL/PUSH-LPR/FWD
SHAFT		 1C9055
9 DOLLY,
ASSY/DISASSY-FRAME		 1C9103
10 FIXT,LIFT-LPCR
SHAFT		 1C9104
11 FIXT,LIFT-FWD
LPC		 1C9116
12 ADAPTER, SLEEVE
– LPT SHAFT		 1C9316
13 Adapter, Support/Lift – LPC 1C9317
14 Fixture Assembly, Install/Remove – Aft
Drive Shaft Nut		 1C9336
15 Fixture, Forward Restrain – LPT
Rotor/Stator		 1C9338
16 FIXTURE, LIFT
& GUIDE TRF/LPT		 1C9345
17 Fixture Assy, Lift – HPT Rotor
Horizontal		 1C9358
18 ADAPTER,ASSY,
LIFT-COMBUSTOR & STG		 1C9362
19 ADAPTER ASSY,
BALANCE – LP TURB ASSY		 1C9366
20 Maintenance Dolly, External Engine 1C9372
21 Adapter Set, Assy, TRF 1C9373
22 Adapter Set, Air Collector Support 1C9375
23 Jack Assembly, CRF Support 1C9376
24 Adapter Set, LPC Support 1C9377
25 FIXT.
SUPPORT-LPC ROTOR/STATOR		 1C9385
26 FIXTURE, LIFT
& TURN-BALANCE PISTON		 1C9388 / 1C9389
27 PULLER – BLADE
RETAINER,		 1C9392
28 HOLDER, SHIM 1C9397
29 FIXTURE,POSITIONING
– COMPR STATOR VANES, STG 3,4 & 5		 1C9405
30 Fixture, HPC Dummy Stator Case 1C9413
31 Stand – HPT Rotor Stage 2 Nozzle –
Horiz		 1C9417
32 TOOL SET, REMOVE
– CRF AFT CASE		 1C9429
33 JACK ASSY,
SUPPORT – COMPR REAR FRAME (SAC)		 1C9448
34 BALANCE,
VERTICAL-LPTR DISK 1-5 (HP CONSULTING)		 1C9603
35 FIXTURE, I/R-HP
TURB MODULE ASSY		 1C9608
36 ADAPTER ASSY,
DRIVE – REAR		 1C9609
37 Pilot, LP Mid-Shaft – Aft 1C9610
38 ADAPTER,
BALANCE-LPT ASSY		 1C9612
39 Fixture, Seat Check – Coupling Nut,
Shaft, LPT Rotor		 1C9616
40 Fixture, Install/Remove – Retainer
Ring LPT/Mid-Shaft		 1C9618
41 Fixture, Torque – LPT Shaft Coupling
Nut		 1C9619
42 Gage Inspection – Fan Shaft to HPT
Stator Case		 1C9620
43 FIXTURE,
CENTERING & SUPPORT – MID SHAFT		 1C9622
44 TRUCK-FAN SHAFT 1C9623
45 Torque Adapter, Pressure Tube/Coupling
Nut-HPT Rotor		 1C9626
46 Fixture, Adjustable C.G. Horizontal
Lift		 1C9627
47 Dolly, Storage, LPT Module 1C9632
48 ADAPTER FWD STG
3-9 COMPR SPOOL (A286 ROTOR)		 1C9646
49 Puller, High Force – LPT Module Mid
Shaft 		 1C9650
50 Pusher, LPT Shaft Bushing 1C9651
51 ARBOR, BUILD UP 2C14011
52 FIXTURE, LIFT
& TURN – COMPR ROTOR AFT		 2C14014
53 STAND,
REWORK/STORAGE – HP TURB ROTOR		 2C14048
54 FIXTURE,
SEATCHECK – NO.4B BEARING & SEAL		 2C14094
55 Fixture, Seat
Check – HPT Rotor		 2C14131
56 STAND,
SHIPPING/STORAGE HP TURB MODULE		 2C14193
57 Fixture, Install/Remove – HPT Module
Assembly		 2C14199
58 FIXTURE,RMV-THERM
SHIELD HOOK BOLT		 2C14238
59 PLATFORM,
SUPPORT-HPTR BUILD TABLE		 2C14250
60 ADAPTER, TORQUE 2C14290
61 PULLER-FWD SUMP
CLOSURE NO.5 BRG		 2C14618
62 FIXTURE,INSTALL/REMOVE
CMPRSR CRF ASSY		 2C14661
63 Wrench Set, No. 5R Bearing Inner Race
Nut		 2C14664
64 Fixture, Lift – HPT Assy, Forward 2C14672
65 SUPPORT, SUMP
HSG – CRF, AFT		 2C14675
66 Sleeve, Retaining – No. 4B Bearing
Stack-Up		 2C14679
67 Puller, Races and Seals – HPT Rotor
Stage 1		 2C14688
68 ADAPTER, LIFT –
COMBUSTOR		 2C14689
69 FIXTURE –
INSTALL/REMOVE COMBUSTOR		 2C14691
70 Guide Clamps 2C14693
71 PULLER, HEAT
SHIELD -NO. 4R BEARING		 2C14694
72 FIXTURE,LIFT-STG
1 HPT NOZZLE ASSY		 2C14695
73 FIXTURE,INSTL/RMV
AIR TUBE HPT#2 NO		 2C14718
74 PULLER, HPT
STAGE 1 SHROUD		 2C14727
75 Fixture, Remove – HPT Rotor Aft Outer
Air Seal		 2C14784
76 Fixture, Pull – HPT Rotor Aft Air
Seals		 2C14785
77 Fixture, Pull – HPT Rotor Aft Air
Seals		 2C14785
78 PULLER, NO. 6
BRG OUTER RACE		 2C14883
79 ADAPTER,BAL 3-9
SPOOL (AFT) & 11-14 SPOOL-SHAFT (FWD),HPCR		 2C14903
80 ADAPTER,BAL-STG
10 CMPRSR DISK & BL		 2C14905
81 RACE SET, SLAVE
– HPT		 2C14913
82 STAND
MAINTENANCE – ENGINE VERTICAL		 2C6054
83 PUSHER,SPACER,AIR
& OIL SEAL,#1 BRG		 2C6120
84 PULLER, INNER
RACE – NO. 2 BEARING		 2C6129
85 SLING,FRAME,LIFTING
& CLEANING,VERT		 2C6168
86 18" ULTRARON ROTARY TABLE 2C6625
87 PYLON, INDICATOR STAND 2C6629
88 EYE, LIFT – HPC
FWD.		 2C6800
89 Gage Set, VSV Clevis 2C6925
90 GAGE,SIGHT-CSV
LVR ARMS(CONN((INSTL		 2C6962
91 GAGE,INSP-VSV
LVR ARMS(LVR ARM RMVD		 2C6963
92 Gage, Sight – VSV Actuation Arms 2C6966
Item # Description LM2500 Part #
1 rework/storage stand 1c5830
2 No. 5R Conc. Gage 1c5937
3 SLING – LIFT – HPT Nozzle Assy, Stage
2		 1c5964
4 LPT aft seal/brg puller 1c6801
5 TRF install guide 1c6802
6 LPT Rotor transport/storage 1c6806
7 TRF stand 1c6840
8 #7 nut wrench LPT config 1 1c6846
9 LPT assy/disassy stand 1c6864
10 fixture drive LPTR  1c6868
11 assy/disassy stand platforms 1c6870
12 LPT aft shaft lift eye 1c6891
13 #5 Bearing wrench and Anchor  1c6897
14 #5 I/R puller/clamshells  1c6899
15 drop check tool #7 area 1c6909
16 HPTR nut wrench 1c6950
17 LPT lift fixture 1c6955
18 LPTR disk lift fixture 1c8005
19 HPT Rotor Stand 1c8059
20 HPT Horizontal Lift Fixture 1c8069
21 small G/G lift fixture 1c8200
22 ADAPTER, LIFT 1c9362
23 GAGE,INSPECT FAN SHAFT  1c9629
24 DOLLY, STORAGE LPT MODULE 1c9632
25 ADAPTER, LIFT 2c14703
26 AREA GAGE-STAGE 1 NOZZLE 2c14774
27 ADAPTER,BAL 3-9
SPOOL (AFT) & 11-14 SPOOL-SHAFT (FWD),HPCR		 2c14903
28 SLAVE BLADE RETAINER 2c14920
29 fwd shaft lifteye 2c6023
30 HPCR dolly 2c6024
31 #4B spanner wrench 2c6027
32 air duct removal tool L21788 2c6030
33 oil tube wrench, socket 2C6058
34 assy/disassy HPTR stand 2c6061
35 HPTR instal/remove fixture –
horizontal/Vertical/1c6950		 2c6062
36 combustor lift fixture-Horizontal 2c6066
37 No. 5R Bearing Nut 2c6084
38 PULLER – No. 5 Inner Race 2c6194
39 No.5 Inner Race Pusher 2c6196
40 HPTR horizontal dolly 2c6264
41 Spline wrench/lolly pop 2c6341
42 Damper Sleeve Removal 2c6563
43 Guide Pins – Stage 2 Nozzle 2c6610
44 18" ULTRARON ROTARY TABLE 2c6625
45 PYLON, INDICATOR STAND 2c6629
46 hook bolt install tool 2c6888
