GEC 4250kVA Frame AG 119 M80 Alternator

Part No: GEC 4250kVA Alternator
ANTONI No: GEC 4250kVA Alternator (AN/NI)
Model: GEC Frame AG 119 M80



4250 kVA each, GEC
(Rugby, U.K.) make Synchronous Alternator having the following
Technical Specifications :

Technical Details :

Manufacturer : GEC
Machines Ltd. – Rubgy,  U.K.

Frame
: AG 119 M80

Sr. No. : J41472202

Year of manufacture :    1980

Output
: 4250 kVA

kW : 3400 kW

Speed : 1500 RPM

Voltage : 11 kV

Frequency : 50 Hz

No. Of Phase : 3

No. Of Poles :  4

Current : 223 A



4250
kVA GEC make Synchronous
Alternator

 Power factor :   0.8

Insulation

(according to IEC 85 standard): Class F

Rating : MCR

Altitude : 1000 M

Connection : Star

Supply  : A.C.

Excitation System :

 Manufacturer:GEC
Machines Ltd. – Rubgy, U.K.

Type :   Brushless Excitor

Frame : OAJ 34 M18

Sr. No. : 5588/1

Year of manufacture :    1980

Excitation Amps : 5.3 A

Excitation Voltage :       67
V

Insulation Class : F

 Condition :Currently
In Storage. In Very Good Working Condition. The Alternator is completely
overhauled & tested. The Test Reports will be handed over to the client.
