Frame 5 N / P / NT Compressor Rotor Blades, Stators, IGV’s, Carrier Rings
Frame 5: 16 or 17 stage
Rotating sets C-450 first 4 stages
Stationary sets include EGV’s & shims / keys C-450
first 4 stages
IGV’s 64 C-450 high flow
Carrier rings – 1st 4 rows
Frame 5 –
Rotating Blades
N-PR00A –
722C762Pxxx
N-PR01A –
722C763Pxxx
N-PR02A –
722C763Pxxx
N-PR03A –
722C764Pxxx
N-PR04A –
319C908Pxxx
N-PR05A –
319C909Pxxx
N-PR06A –
319C909Pxxx
N-PR07A –
319C909Pxxx
N-PR08A –
319C909Pxxx
N-PR09A –
319C910Pxxx
N-PR10A –
319C910Pxxx
N-PR11A –
319C910Pxxx
N-PR12A –
319C910Pxxx
N-PR13A –
319C911Pxxx
N-PR14A –
319C911Pxxx
N-PR15A –
319C911Pxxx
N-PR16A –
719C657Pxxx
Frame 5 –
Stationary Blades
N-PS00A (Our Part # just the
blade) – 143B223G006 – Blade and Ring Stage 0
N-PS01A (Our Part # just the
blade) – 143B224G002 – Blade and Ring Stage 1
N-PS02A (Our Part # just the
blade) – 143B225G008 – Blade and Ring Stage 2
N-PS03A (Our Part # just the
blade) – 143B226G008 – Blade and Ring Stage 3
Frame 5 Stator Rings
G5-SR00A-1 – F5 Stator Ring Seg.
1, Row 0 – Qty. 2
G5-SR00A-2 – F5 Stator Ring Seg.
2, Row 0 – Qty. 1
G5-SR00A-3 – F5 Stator Ring Seg.
3, Row 0 – Qty. 1
G5-SR01A-1 – F5 Stator Ring Seg.
1, Row 1 – Qty. 1
G5-SR01A-2 – F5 Stator Ring Seg.
2, Row 1 – Qty. 1
G5-SR01A-3 – F5 Stator Ring Seg.
3, Row 1 – Qty. 1
G5-SR01A-4 – F5 Stator Ring Seg.
4, Row 1 – Qty. 1
G5-SR02A-1 – F5 Stator Ring Seg.
1, Row 2 – Qty. 1
G5-SR02A-2 – F5 Stator Ring Seg.
2, Row 2 – Qty. 1
G5-SR02A-3 – F5 Stator Ring Seg.
3, Row 2 – Qty. 2
G5-SR03A-1 – F5 Stator Ring Seg.
1, Row 3 – Qty. 1
G5-SR03A-2 – F5 Stator Ring Seg.
2, Row 3 – Qty. 1
G5-SR03A-3 – F5 Stator Ring Seg.
3, Row 3 – Qty. 2
Frame 5 Shims
G5-SR00-01A-045 – F5 STATOR RING
.045” SHIM ROWS 0-1 – QTY. 4
G5-SR00-01A-060 – F5 STATOR RING
.060” SHIM ROWS 0-1 – QTY. 4
G5-SR00-01A-075 – F5 STATOR RING
.075” SHIM ROWS 0-1 – QTY. 4
G5-SR02-045 – F5 STATOR RING
.045” SHIM ROW 2 – QTY. 2
G5-SR02-060 – F5 STATOR RING
.060” SHIM ROW 2 – QTY. 2
G5-SR02-075 – F5 STATOR RING
.075” SHIM ROW 2 – QTY. 2
G5-SR03-045 – F5 STATOR RING
.045” SHIM ROW 3 – QTY. 2
G5-SR03-060 – F5 STATOR RING
.060” SHIM ROW 3 – QTY. 2
G5-SR03-075 – F5 STATOR RING
.075” SHIM ROW 3 – QTY. 2
N-PS04A –
719C255P007
N-PS04HJ1A –
719C255P008
N-PS04HJ2A –
719C255P009
N-PS05A –
719C256P007
N-PS05HJ1A –
719C256P008
N-PS05HJ2A –
719C256P009
N-PS06A –
719C257P007
N-PS06HJ1A –
719C257P008
N-PS06HJ2A –
719C257P009
N-PS07A –
719C258P007
N-PS07HJ1A –
719C258P008
N-PS07HJ2A –
719C258P009
N-PS08A –
718C975P007
N-PS08HJ1A –
718C975P008
N-PS08HJ2A –
718C975P009
N-PS09A –
718C976P001
N-PS09HJ1A –
718C976P002
N-PS09HJ2A –
718C976P003
N-PS10A –
718C977P001
N-PS10HJ1A –
718C977P014
N-PS10HJ2A –
718C977P015
N-PS11A –
718C978P001
N-PS11HJ1A –
718C978P002
N-PS11HJ2A –
718C978P003
N-PS12A –
718C979P001
N-PS12HJ1A –
718C979P002
N-PS12HJ2A –
718C979P003
N-PS13A –
718C980P001
N-PS13HJ1A –
718C980P002
N-PS13HJ2A –
718C980P003
N-PS14A –
718C981P001
N-PS14HJ1A –
718C981P002
N-PS14HJ2A –
718C981P003
N-PS15A –
718C982P001
N-PS15HJ1A –
718C982P002
N-PS15HJ2A –
718C982P003
N-PS16A –
718C983P001
N-PS16HJ1A –
718C983P002
N-PS16HJ2A –
718C983P003
N-PSEGV1A –
718C984P001
N-PSEV1HJ1A –
718C984P002
N-PSEV1HJ2A –
718C984P003
N-PSEGV2A –
718C985P001
N-PSEV2HJ1A –
718C985P002
N-PSEV2HJ2A –
718C985P003
N-PIGVA –
151D8782P001
N-PS00SPLA – qty. 4 – Blades in
the carrier rings that get cut to match the rings.
N-PS01SPLA – qty. 4 – Blades in
the carrier rings that get cut to match the rings.
N-PS02SPLA – qty. 4 – Blades in
the carrier rings that get cut to match the rings.
N-PSS04-07A-030 – F5 STATIONARY
.030” SHIM ROWS 4-7 – Qty. – 15
N-PSS04-07A-045 – F5 STATIONARY
.045” SHIM ROWS 4-7 – Qty. – 20
N-PSS04-07A-060 – F5 STATIONARY
.060” SHIM ROWS 4-7 – Qty. – 40
N-PSS04-07A-075 – F5 STATIONARY
.075” SHIM ROWS 4-7 – Qty. – 30
N-PSS08-11A-030 – F5 STATIONARY
.030” SHIM ROWS 8-11 – Qty. – 15
N-PSS08-11A-045 – F5 STATIONARY
.045” SHIM ROWS 8-11 – Qty. – 20
N-PSS08-11A-060 – F5 STATIONARY
.060” SHIM ROWS 8-11 – Qty. – 40
N-PSS08-11A-075 – F5 STATIONARY
.075” SHIM ROWS 8-11 – Qty. – 30
N-PSS12-16A-030 – F5 STATIONARY
.030” SHIM ROWS 12-16 – Qty. – 15
N-PSS12-16A-045 – F5 STATIONARY
.030” SHIM ROWS 12-16 – Qty. – 20
N-PSS12-16A-060 – F5 STATIONARY
.030” SHIM ROWS 12-16 – Qty. – 40
N-PSS12-16A-075 – F5 STATIONARY
.030” SHIM ROWS 12-16 – Qty. – 30
N-PSKEY-1 – 211A8224P002 –
37-3/8” X ¼” X ¼” – QTY. 8
N-PSKEY-2 – 298A0111P012 –
20-3/8” X ¼” X ¼” – QTY. 2
N-PSKEY-3 – 298A0111P013 –
25-3/8” X ¼” X ¼” – QTY. 2
